Cooling Fans
Architecture
|
Delivering 2,500 square feet of cooling coverage with 32-gallon evaporative capacity and explosion-proof models rated for Class I Division 2 hazardous locations, our 36-inch cooling fans provide essential climate control and personnel comfort for demanding offshore environments
Category
Power, Lighting & Ventilation
Specs
36” CLASSIC COOLING FAN
Speeds
1 Speed / 3 Speed
Cooling capacity
2,500 s.f. / 230 m2
Water reservoir
32 G / 120 L
Dimensions (inches)
67 H x 63 W x 32 D
Weight
191 lb / 87 kg
Electrical requirements
Standard 115v
HAZARDOUS/EXPLOSION PROOF FANS
Hazardous Location
Class l Div. 2 Groups C, D
Speeds
1 Speed
Cooling capacity
2,500 s.f. / 230 m2
Water reservoir
32 G / 120 L
Dimensions (inches)
67 H x 63 W x 32 D
Weight
191 lb / 87 kg
Electrical requirements
Standard 115v
Powerful Cooling Performance Our 36-inch cooling fan systems deliver substantial air movement covering up to 2,500 square feet, providing essential ventilation and temperature relief for offshore work areas, equipment rooms, and personnel spaces during hot weather operations. The large-diameter fan generates significant airflow that combats heat stress, improves air circulation in confined spaces, and creates comfortable working conditions that maintain crew productivity and safety during extended shifts. Available in both classic multi-speed configurations (1-speed or 3-speed options) and explosion-proof models for hazardous locations, these fans provide the versatile cooling solutions necessary for diverse offshore applications from machinery rooms and workshop areas to temporary shelters and break spaces.
Evaporative Cooling Capability Maximize cooling effectiveness with integrated 32-gallon water reservoir capacity that enables evaporative cooling for enhanced temperature reduction in hot, dry conditions. The substantial water capacity provides hours of continuous evaporative operation without frequent refilling, delivering cooler discharge air that reduces ambient temperatures more effectively than air circulation alone. This evaporative function proves especially valuable during summer operations in hot climates where heat stress threatens worker safety and productivity, or in enclosed spaces where air conditioning is impractical or unavailable. The large reservoir minimizes maintenance interruptions, allowing extended operation during critical work periods when stopping to refill cooling systems disrupts operations and reduces efficiency.
Hazardous Location Certification Deploy cooling equipment safely in classified offshore areas with explosion-proof fan models certified for Class I Division 2 Groups C and D hazardous locations. These specially designed units feature sealed motors, explosion-proof electrical components, and construction that prevents ignition sources in atmospheres containing flammable gases or vapors. This certification allows cooling operations near process equipment, in pump rooms, around wellheads, and in other classified areas where standard fans pose unacceptable ignition risks. The hazardous location rating eliminates the need for complex hot work permits or area declassification procedures, allowing immediate deployment of cooling equipment wherever heat stress threatens personnel safety or equipment performance without compromising platform safety protocols.
Portable & Practical Design Maneuver easily throughout platform areas with portable cooling units dimensioned at 67"H x 63"W x 32"D and weighing 191 pounds—substantial enough for stability during platform motion yet manageable for repositioning as work locations change. The wheeled design facilitates movement between deck areas, equipment spaces, and work zones without requiring lifting equipment or multiple personnel. Standard 115-volt electrical requirements integrate seamlessly with existing platform power distribution, eliminating the need for specialized electrical installations or dedicated circuits. Whether cooling equipment rooms during maintenance, providing ventilation in welding areas, or delivering comfort cooling in accommodation spaces, these fans deploy rapidly wherever cooling needs arise throughout your offshore operations.
Worker Safety & Productivity Protect personnel from heat-related illnesses and maintain operational productivity during high-temperature conditions with professional-grade cooling equipment designed for industrial offshore environments. Heat stress represents a serious safety concern during summer operations, heavy physical work, and in machinery spaces where equipment generates significant thermal loads. Adequate cooling and ventilation reduce fatigue, improve concentration, lower injury risks associated with heat exhaustion, and maintain the alertness essential for safe operations in hazardous offshore environments. The substantial airflow improves overall air quality by promoting circulation and reducing stagnant areas where fumes, humidity, and heat accumulate. Available in both standard and explosion-proof configurations to match your specific area classifications, these cooling fans deliver the climate control that keeps crews safe, comfortable, and productive regardless of ambient conditions. Backed by our equipment availability and rapid deployment capability, you maintain proper environmental controls that protect your most valuable asset—your personnel—throughout every season and operational condition.
